Fieldbus PCI-Card

Principle of Input/Outputs in ASI

9.3 Principle of Input/Outputs in ASI

Note

For every Input or Output in ASI the respective Input/Output will be allocated (blocked).

The Inputs/Outputs of the nodes in an ASI fieldbus system can be set up as in following example:

I/O NO: Function Comment

25-32 8 bits of system status For NX100 specific fieldbus status

data

33-36 4 bits of system status For ASI fieldbus system internal

status data.

Always 4 first bits of the first node in

ASI.

37-40 4 bits of data input Node 1

4 bits of data output

41-44 4 bits of data input Node 2

4 bits of data output

45-48 4 bits of data input Node 3

4 bits of data output

49-52 4 bits of data input Node 4

4 bits of data output

9.4 Configuration interface

This interface provides a simple text based interface via the onboard RS232 interface. All network

configuration parameters are available using a standard terminal emulator such as the windows

Hyperterminal.

Note

No data exchange is halted and no mailbox activity is possible while using this interface.

Terminal emulation:

ASCII

Baudrate: 38400

Databits:

Stopbits: 1

Parity: None

Flow control: None

Reg.No. ME00107EN-02 Page 41
