3.19 Dimensional Drawings of SGMCS Servomotors
3-155
3
3.19.7 Servomotor Connector for All Small-capacity Series Servomotors
• Servomotor-end Connector Cable Specifications
• Encoder-end Connector Cable Specifications
Model: JN1AS04MK2
Manufacturer: Japan Aviation Electronics Industry, Ltd.
Applicable plug: JN1DS04FK1
(Provided by the customer.)
1
2
3
4
Phase U
Phase V
Phase W
FG
(Frame ground)
1
3
2
4
10
1
2
3
4
5
PG5V
PG0V
6
∗PS
7
8
9
PS
FG
(Frame ground)
1
3
4
7
8
10
Model: JN1AS10ML1
Manufacturer: Japan Aviation Electronics Industry, Ltd.
Applicable plug: JN1DS10SL1
(Provided by the customer.)
