YASKAWA SGM H Series - Digital Operator

5 Specifications and Dimensional Drawings of Cables and Peripheral Devices
5.8.2 Digital Operator
5-58
(3) 14-pin Half-pitch Connector Cable for NEC PC-98 Series PC
(a) Cable Type: JZSP-CMS03
(b) Dimensional Drawing
5.8.2 Digital Operator
(1) Model JUSP-OP02A-2 with a 1m (3.28 ft)-connection Cable
(2) Dimensional Drawing
Label
81
14 7
81
14 7
2
× M2.6 screws
5 (0.20)
39 (1.54)
Half-pitch connector
Plug: 10114
3000VE
Shell: 10314
52A0 008
(Sumitomo 3M Ltd.)
Half-pitch connector
Plug: 10114
3000VE
Shell: 10314
52F0 008
(Sumitomo 3M Ltd.)
39 (1.54)
29.5 (1.16)
Personal computer end
SERVOPACK end
Cable:
AWG26
× 3C UL2464
2000±50 (78.74±1.97)
29.5 (1.16)
Units: mm (in)
Personal computer end
Signal Pin No.
Case
SERVOPACK end
SignalPin No.
14
−
GND
−
−−
RXD
TXD
RTS
CTS
GND
FG
FG
1
9
10
4
14
12
Case
TXD
RXD
FG
2
4
Shield wire
Connect
to CN3
SERVOPACK
Digital Operator
YASKAWA
CN3
2 (0.08) ×φ4.5 (0.18)
mounting holes
125 (4.92)
135 (5.31)
63 (2.48)
Units: mm (in)
18.5 (0.73)
7 (0.28)
50 (1.97)
YASKAWA
26 (1.02)
(8)
(0.31)
39 (1.54)
29.5 (1.16)
