YASKAWA SGM H Series - Cables for SGMGH;SGMSH;SGMDH Servomotors

2.5 Selecting Cables
2-23
2
2.5.2 Cables for SGMGH/SGMSH/SGMDH Servomotors
Name
Servomotor
Model
Length Type Specifications
Refer-
ence
d
Servomotor
Main Circuit
Cables and
Connectors
(Cont’d)
For standard
environment
connector kit
without
brakes
SGMAH
30 W to 750 W
SGMPH
100 W to 750 W
JZSP-CMM9-1
5.2.2
SGMPH
1.5 kW
JZSP-CMM9-3
For standard
environment
connector kit
with brakes
SGMAH
30 W
to
750 W
SGMPH
100 W
to
750 W
JZSP-CMM9-2
SGMPH
1.5 kW
JZSP-CMM9-4
YASKAWA
SERVOPACK
SGDM-
200V
L1
L2
L3
U
V
W
L1C
L2
B1
B2
B3
1
2
C
N
3
C
N
1
C
N
2
MODE/SET DATA/
CHARGE
POWER
CN2


