5.2 Servomotor Main Circuit Wire Size and Connectors
5-9
5
(4) 200 V SGMGH Servomotors for 1000 min
-1
(5) 200 V SGMSH Servomotors
(6) 200 V SGMDH Servomotors
(7) 200 V SGMCS Servomotors
5.2.2 SGMAH and SGMPH Servomotor Connectors for Standard Environments
The SGMAH and SGMPH servomotors do not conform to the IEC’s IP67 classification (IP67 Protective Con-
struction Standard) and the European Safety Standards.
(1) 30 to 750 W SGMAH Servomotor Connector Kit
(2) 100 W to 1.5 kW SGMPH Servomotor Connector Kit
Rated Output 300 W 600 W 900 W 1.2 kW 2.0 kW 3.0 kW 4.0 kW 5.5 kW
Three-phase
200 V
HIV2.0 HIV3.5 HIV5.5 HIV8 HIV14
Rated Output 1.0 kW 1.5 kW 2.0 kW 3.0 kW 4.0 kW 5.0 kW
Three-phase
200 V
HIV2.0 HIV3.5 HIV5.5 HIV8
Rated Output 2.2 kW 3.2 kW 4.0 kW
Three-phase
200 V
HIV5.5 HIV8
Servomotor
model
02B 05B 07B 04C 10C 14C 08D 17D 25D 16E 35E
Rated output
42 W 105 W 147 W 84 W 209 W 293 W 168 W 356 W 393 W 335 W 550 W
Wire size
AWG20
Servomotor
model
45M 80M 1AM 80N 1EN 2ZN
Rated output
707 W 1.26 kW 1.73 kW 1.26 kW 2.36 kW 3.14 kW
Three-phase
200 V
HIV2.0 HIV3.5 HIV2.0 HIV3.5 HIV5.5
Applicable Servomotor Models Type
100 V: 30 to 200 W
200 V: 30 to 750 W
Without brakes JZSP-CMM9-1
With brakes JZSP-CMM9-2
Applicable Servomotor Models Type
100 V: 100 W and 200 W
200 V: 100 to 750 W
Without brakes JZSP-CMM9-1
With brakes JZSP-CMM9-2
200 V: 1.5 kW
Without brakes JZSP-CMM9-3
With brakes JZSP-CMM9-4
