YASKAWA SGM H Series - Three-Phase 200 V: 2.0 Kw;3.0 Kw (20 AD to 30 AD, 20 ADA to 30 ADA)

4.7 Dimensional Drawings of Base-mounted SERVOPACK Model
4-21
4
4.7.5 Three-phase 200 V: 2.0 kW/3.0 kW (20AD to 30AD, 20ADA to 30ADA)
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
Cooling fan
Heat sink
2×φ6 (φ0.24) holes
CN1
CN2
CN3
CN1
CN2
(100°)
CN3
6
(0.24)
YASKAWA SERVOPACK
SGDM-
14-pin terminal
M4 mounting
screw
250 (9.84)
238.5 (9.39)
6 (0.24)
100 (3.94)
110 (4.33)
75 (2.95)*
180 (7.09)
4 (0.16)
5.5* (0.22)
5 (0.20)*
5
(0.20)*
40
(1.57)*
250 (9.84)
238.5±0.5 (9.39±0.02)
100±0.5
(3.94±0.02)
110 (4.33)
5.5 (0.22)*
5
(0.20)*
5 (0.20)*
6 (0.24)
MODE/SET
CHARGE POWER
DATA/
YASKAWA
Ground terminal
2×M4 screws
Nameplate
Nameplate
(Mounting pitch)
4×M5 tap
Mounting Hole Diagram
(Mounting pitch)
* Reference length
Units: mm (in)
Approx. mass: 3.8 kg (8.38 lb)
L1C L2CL2 L3L1
200 VAC
50/60 Hz
Three-phase
200 VAC
50/60 Hz
Single-phase
Main circuit
power supply
Control power
supply
