4.7 Dimensional Drawings of Base-mounted SERVOPACK Model
4-17
4
4.7 Dimensional Drawings of Base-mounted SERVOPACK Model
4.7.1 Single-phase 100 V: 30 W to 100 W (A3BD to 01BD, A3BDA to 01BDA)
Single-phase 200 V: 30 W to 200 W (A3AD to 02AD, A3ADA to 02ADA)
External Terminal Connector
SERVOPACK Connector
Connector
Symbol
SERVOPACK
Connector Model
Manufacturer
CN1 10250-52A2JL Sumitomo 3M Co., Ltd.
CN2 53460-0611 Molex Japan Co., Ltd.
CN3 10214-52A2JL Sumitomo 3M Co., Ltd.
2×M4 screw holes
Mounting Hole Diagram
Terminal
block
Nameplate
* Reference length
Units: mm (in)
Approx. mass: 0.8 kg (1.76 lb)
(Mounting pitch)
160 (6.30)
5
(0.20)
5.5 (0.22)
149.5±0.5 (5.89±0.02)
CN3
CN2
CN1
55 (2.17)
160 (6.30)
10
(0.39)
6
(0.24)
6 (0.24)
130 (5.12)
75 (2.95) *
17 (0.67)
5 (0.20) *
YASKAWA
YASKAWA
SERVOPACK
SGDM-
55 (2.17)
MODE/SET
CHARGE POWER
DATA/
Ground terminal
2×M4 screws
L1 L2
Main circuit
power supply
Control power
supply
Single-phase
100/200 VAC
50/60 Hz
L1C L2C
Single-phase
100/200 VAC
50/60 Hz
