5.8 Peripheral Devices
5-79
5
(2) Dimensional Drawings
DC Reactor
Model
Dimensions in mm (in) Approx.
Mass
in kg (lb)
ABCDEFGφH φI
X5059
50
(1.97)
74
(2.91)
125
(4.92)
140
(5.51)
35
(1.38)
45
(1.77)
60
(2.36)
5
(0.20)
5.3
(0.21)
1.1
(2.43)
X5060
40
(1.57)
59
(2.32)
105
(4.13)
125
(4.92)
45
(1.77)
60
(2.36)
65
(2.56)
4
(0.16)
4.3
(0.17)
1.0
(2.20)
X5061
35
(1.38)
52
(2.05)
80
(3.15)
95
(3.74)
35
(1.38)
45
(1.77)
50
(1.97)
4
(0.16)
4.3
(0.17)
0.5
(1.10)
X5062
40
(1.57)
59
(2.32)
100
(3.94)
120
(4.72)
40
(1.57)
50
(1.97)
55
(2.17)
4
(0.16)
4.3
(0.17)
0.9
(1.98)
X5063
35
(1.38)
52
(2.05)
90
(3.54)
105
(4.13)
35
(1.38)
45
(1.77)
50
(1.97)
4
(0.16)
4.3
(0.17)
0.6
(1.32)
X5068
50
(1.97)
74
(2.91)
125
(4.92)
155
(6.1)
53
(2.09)
66
(2.6)
75
(2.95)
5
(0.20)
6.4
(0.25)
1.9
(4.19)
X5069
40
(1.57)
59
(2.32)
105
(4.13)
125
(4.92)
45
(1.77)
60
(2.36)
65
(2.56)
4
(0.16)
4.3
(0.17)
1.0
(2.20)
X5070
40
(1.57)
59
(2.32)
100
(3.94)
120
(4.72)
35
(1.38)
45
(1.77)
50
(1.97)
4
(0.16)
4.3
(0.17)
0.8
(1.76)
X5071
35
(1.38)
52
(2.05)
80
(3.15)
95
(3.74)
30
(1.18)
40
(1.57)
45
(1.77)
4
(0.16)
4.3
(0.17)
0.5
(1.10)
 ×φ 







φ 

  

