YASKAWA SGM H Series - Page 62

2.5 Selecting Cables
2-25
2
c
Encoder
Cables
(Cont’d)
* Applicable for
every type
and capacity.
For IP67 specification
encoder end connector
JA06A-20-29S-J1-EB
Straight plug
5.5.2
JA08A-20-29S-J1-EB
L-shaped plug
JL04-2022CKE (09)
Cable diameter:
φ
6.5 to
φ
9.5 mm
(
φ
0.26 to
φ
0.37 in)
Cable clamp
JL04-2022CKE (12)
Cable diameter:
φ
9.5 to
φ
13 mm
(
φ
0.37 to
φ
0.51 in)
JL04-2022CKE (14)
Cable diameter:
φ
12.9 to
φ
15.9 mm
(
φ
0.51 to
φ
0.63 in)
SERVOPACK end
connector kit
JZSP-CMP9-1
Soldered
5.5.2
Cables
5 m
(16.4 ft)
JZSP-CMP09-05
5.5.2
10 m
(32.8 ft)
JZSP-CMP09-10
15 m
(49.2 ft)
JZSP-CMP09-15
20 m
(65.6 ft)
JZSP-CMP09-20
30m
(98.4 ft)
JZSP-CMP19-30
40m
(131.2 ft)
JZSP-CMP19-40
50m
(164.0 ft)
JZSP-CMP19-50
Name Length Type Specifications
Refer-
ence
CN2
20 m (65.6 ft) max.
50 m (164.0 ft) max.
