2.6 Selecting Peripheral Devices
2-31
2
* For details, refer to the manuals of each application module.
d Digital Operator
JUSP-OP02A-2
With connection cable (1 m (3.28 ft))
5.8.2
e
Connection Cable for Digital Op-
erator
1m
(3.28 ft)
JZSP-CMS00-1
Only required when using
Σ
series
Digital Operator JUSP-OP02A-1.
1.5m
(4.92 ft)
JZSP-CMS00-2
2 m
(6.56 ft)
JZSP-CMS00-3
f
Connection Cable for Personal
Computer
2 m
(6.56 ft)
JZSP-CMS01
D-Sub 25-pin (For PC98)
5.8.1
2 m
(6.56 ft)
JZSP-CMS02
D-Sub 9-pin (For DOS/V)
2 m
(6.56 ft)
JZSP-CMS03
Half-pitch 14-pin (For PC 98)
g
Analog Monitor Cable
1 m
(3.28 ft)
JZSP-CA01 or
DE9404559
5.8.3
h
Battery for Absolute Encoder
JZSP-BA01
To mount in the SERVOPACK
(30 W to 5.0 kW)
5.8.8
JZSP-BA01-1
To mount in the SERVOPACK
(6.0 kW to 15.0 kW)
ER6VC3
To connect to a host controller (pro-
vided by a customer)
3.6 V 2000 mAh
,
manufactured by Toshiba Battery
Co., Ltd.
Name Length Type Specifications
Refer-
ence
CN3
Operator
end
SERVOPACK
end
CN3
Personal
computer end
SERVOPACK
end
Personal
computer end
SERVOPACK
end
Personal
computer end
SERVOPACK
end
CN5
SERVOPACK end
Monitor end
CN8
