4-52
U1-16
Terminal A2
input level
Monitors the input level of
analog input A2. A value of
100% corresponds to 10V/
20mA input.
10 V/20mA: 100%
(0 to ±10 V possible)
0.1% A A A 4FH
Term A2
Level
U1-18
Motor sec-
ondary cur-
rent (Iq)
Monitors the calculated value
of the motor secondary cur-
rent.
The motor rated current corre-
sponds to 100%.
10 V:Motor rated current)
(0 to ±10 V output)
0.1% A A A 51H
Mot SEC
Current
U1-19
Motor excita-
tion current
(Id)
Monitors the calculated value
of the motor excitation cur-
rent.
The motor rated current corre-
sponds to 100%.
10 V:Motor rated current)
(0 to ±10 V output)
0.1% No A A 52H
Mot EXC
current
U1-20
Frequency
reference
after soft-
starter
Monitors the frequency refer-
ence after the soft starter.
This frequency value does not
include compensations, such
as slip compensation.
The unit is set in o1-03.
10 V: Max. frequency
(0 to ± 10 V possible)
0.01H
z
AA A 53H
SFS Output
U1-21
ASR input Monitors the input to the
speed control loop.
The maximum frequency cor-
responds to 100%.
10 V: Max. frequency
(0 to ± 10 V possible)
0.01
%
No No A 54H
ASR Input
U1-22
ASR output Monitors the output from the
speed control loop.
The maximum frequency cor-
responds to 100%.
10 V:Max. frequency
(0 to ± 10 V possible)
0.01
%
No No A 55H
ASR output
U1-25
DI-16H2
input status
Monitors the reference value
from a DI-16H2 Digital Ref-
erence Card.
The value will be displayed in
binary or BCD depending on
user constant F3-01.
(Cannot be output.) - A A A
58H
DI-16 Refer-
ence
U1-26
Output volt-
age refer-
ence (Vq)
Monitors the Inverter internal
voltage reference for motor
secondary current control.
10 V: 200 VAC
(400 VAC)
(0 to ± 10 V possible)
0.1 V No A A 59H
Voltage
Ref(Vq)
U1-27
Output volt-
age refer-
ence (Vd)
Monitors the Inverter internal
voltage reference for motor
excitation current control.
10 V: 200 VAC
(400 VAC)
(0 to ± 10 V possible)
0.1 V No A A 5AH
Voltage
Ref(Vd)
U1-28
Software No.
(CPU)
(Manufacturer’s CPU soft-
ware No.)
(Cannot be output.) - A A A 5BH
CPU ID
U1-32
ACR output
of q axis
Monitors the current control
output value for the motor
secondary current.
10 V: 100%
(0 to ± 10 V possible)
0.1
%
No A A 5FH
ACR(q)
Output
U1-33
ACR output
of d axis
Monitors the current control
output value for the motor
excitation current.
10 V: 100%
(0 to ± 10 V possible)
0.1
%
No A A 60H
ACR(d) axis
Param-
eter
Number
Name
Description
Output Signal Level
During Multi-Function
Analog Output
Min.
Unit
Control Methods MEMO-
BUS
Regis-
ter
V/f
Open
Loop
Vector
Closed
Loop
Vector
Display
