TG100 User Guide
19/75
4. Click Save and Apply Changes.
Connect TG Gateway to Your PBX (Account Mode)
If you choose account mode, you need to create one VoIP account on TG gateway,
and configure the following settings
Connect TG Gateway to Your PBX (Account Mode)
On your PBX, set up an outbound route for the VoIP trunk
On your PBX, set up an inbound route for the VoIP trunk
Set up a Mobile to IP Route (Account Mode)
Set up an IP to Mobile Route (Account Mode)
Connect TG Gateway to Your PBX (Account Mode)
Procedure
1. Create a VoIP account on TG gateway.
a. Navigate to Gateway > VoIP Settings > VoIP Trunk, click Add VoIP Trunk.
b. Set Trunk Type to Account.
c. Choose a protocol from the Type field.
When you use this account to register VoIP trunk, you should choose the
same protocol.
d. Set the account’s Name, Account and Password.
You need to use the same account number and password to register VoIP
trunk on your PBX.
e. (Optional) Click Advanced tab, and configure the advanced settings.
Network address translation (NAT) is a method of translating
the private (not globally unique) address in Internet Protocol
(IP) into legal address. NAT is used to limit the number of
public IP addresses for security purpose.
Secure Real-time Transport Protocol, if it’s enabled, the same
setting should be enabled on IP phone side.
Send check alive packets to IP phones, when it’s disabled,
TG100 will ignore the reachability and the status of this account
will be out of monitoring.
This will be the transport method used by the account trunk.
UDP (default)
TCP
TLS
