TG100 User Guide
23/75
Trunk, click Add VoIP Trunk.
b. Set Trunk Type to Trunk.
c. Choose a protocol from the Type field. The protocol should be the same as the
PBX extension’s protocol.
d. Set a Provider Name.
e. Enter the PBX’s IP address or domain in Hostname/IP or Domain field.
f. Enter the PBX extension’s number in User Name and Authorization Name
fields.
g. Enter the PBX extension’s password in Password field.
h. (Optional) Click Advanced tab to configure the advanced settings.
All outgoing calls from this SIP Trunk will use the From User in
From Header of the SIP Invite package. Leave this field blank if
not needed.
Define the online number for “Skype Connect” and some other
SIP service providers. Leave this field blank if not needed.
Control the maximum number of simultaneous calls, set as 0 to
specify no limit.
Specify the caller ID to use when making outbound calls over
this trunk.
Define if SRTP is enabled for this trunk, it depends on
provider’s configuration.
Send check alive packets to the SIP provider.
Enable outbound
proxy server
A proxy that receives requests from a client, even though it
may not be the server resolved by the Request-URI.
Define the codec for this SIP trunk and its priority.
This will be the transport method used by the SIP Trunk. This
method is given by the SIP trunk provider.
UDP
TCP
TLS
Set default mode for sending DTMF of this trunk. The default
value is rfc2833.
DOD (Direct Outward Dialing) means the caller ID displayed
when dialing out.
Note: Make sure provider supports this feature before
configuring the setting.
3. Click Save and Apply Changes.
