Outputting Displayed Waveforms and
Setting Parameters to the Printer/Plotter
10
Explanation
Selecting the paper size
The contents of printing, paper size, printing size and printing location can be selected from
the following eight types. However, only one type of output can be selected at a time. “A5-
Upper WAVE” and “A5-Lower WAVE” allow output of two A5-sized screens of information
on a sheet of A4 paper.
Setting Output item Output size Output location
A3-WAVE Screen hardcopy A3 Middle
A3-SETUP Set-up parameters A3 Middle
A4-WAVE Screen hardcopy A4 Middle
A4-SETUP Set-up parameters A4 Middle
A5-Upper WAVE Screen hardcopy A5 Upper half
A5-Lower WAVE Screen hardcopy A5 Lower half
A5-Upper WAVE & Screen hardcopy A5 Upper half
A5-Lower SETUP Set-up parameters A5 Lower half
A5-Upper WAVE & Screen hardcopy A5 Upper half
A5-Lower MEASURE waveform measurement data A5 Lower half
Selecting the pen speed
The pen speed can be selected from the following two speeds.
NORM Plots at the default speed setting.
SLOW Plots at a speed of 10 cm/s.
Selecting the pen assignment method: Pen Mode
The pens can be assigned according to the following two methods.
AUTO Assigns pens automatically, as shown in the table below, according to the number
of pens.
Number of GRID TRACE LOAD
installed pens 12341234
(MATH)
1111111111
2121122112
3123122312
4123412341
5123452345
MANUAL A particular pen can be assigned to the graticule, to TRACE1 to 4 (for DL1520/
DL1520L, 1/2/MATH) and to LOAD 1 to 4 (for DL1520/DL1520L, 1/2). The
pen numbers that can be assigned are 0 to 12. If “0” is selected, no plotting is
performed for the corresponding item.
Assignment of pens to the grid, trace and load
The grid, TRACE1 to TRACE4 and LOAD 1 to LOAD4 can have pens assigned to them as
follows.
Setting Assignment for hardcopy
Grid Graticule, all cursors, trigger position mark, date and time, comments, setup
information list, measurement values
TRACE1 Trace1 waveform, ground level, trigger level mark, voltage axis conditions,
input coupling, probe attenuation
TRACE2 to 4 Same as Trace1
(for DL1520/DL1520L, 2/MATH)
LOAD1 to 4
(for DL1520/DL1520L, 1/2)
Note
For DL1520 with suffix code -C1/-C3 or DL1520L with suffix code -C1/-C3/-C4, enable to print displayed
waveforms and additional information.
10.5 Printing Displayed Waveforms and Additional Information using an External Plotter
