YOKOGAWA DL 1540 User Manual

IM 701510-01E
15-6
No. Message Reference Page
828 (For DL1520L)
A record length of 400K/1M words can only be set when the trigger mode is SINGLE.
(For DL1540L)
A record length of 400K/1M/2M words can only be set when the trigger mode is SINGLE. 7-2
829 (For DL1520L)
A record length of 1M words can only be set when the CH2 and Math operation are both OFF.
(For DL1540L)
A record length of 2M words can only be set when the CH3 and CH4 are both OFF. 7-2
830 (For DL1520L)
Since the record length is 400K/1M words, the trigger mode can only be set to SINGLE.
(For DL1540L)
Since the record length is 400K/1M/2M words, the trigger mode can only be set to SINGLE. 6-13
831 (For DL1520L)
Since the record length is 1M words, CH2 and Math operation cannot be set ON.
(For DL1540L)
Since the record length is 2M words, CH3 and CH4 cannot be set ON. 7-2
900 The back-up lithium battery has run out. The back-up function is no longer valid. To have the battery
replaced, contact your nearest YOKOGAWA representative as listed on the back cover of this manual. 3-6
901 Cooling fan has stopped. Turn OFF the power immediately. —
905 Isolator cannot be used.
15.2 Error Messages and Corrective Actions
