YOKOGAWA DLM3024 User Manual

9-12
IM DLM3054-01EN
BIN (Conversion into Binary Values) Examples
Syntax: BIN(parameter 1, parameter 2, parameter 3)
Parameter 1: Set the waveform to convert into binary values. Enter a waveform or an expression that
contains waveforms.
Parameter 2: Set the upper threshold level. Enter a constant or a constant expression.
Parameter 3: Set the lower threshold level. Enter a constant or a constant expression.
BIN(C1+C2,10+K1/2,10−K1/2) Convert the C1+C2 waveform into binary values with Upper set to
10+K1/2 and Lower set to 10−K1/2
BIN(C2,P.High(C2),P.Low(C2)) Convert waveform C2 into binary values with Upper set to waveform
C2’s high value and Lower set to waveform C2’s low value
BIN(5,10,2) Not allowed because parameter 1 is not a waveform or an expression
that contains waveforms
BIN(C1,C2,−1) Not allowed because parameter 2 is not a constant or a constant
expression
PWHH to DUTYL (Pulse Width Computation) Examples
Syntax: PWHH(parameter 1, parameter 2, parameter 3)
Parameter 1: Set the waveform to compute the pulse width of. Enter a single-term waveform.
Parameter 2: Set the upper threshold level. Enter a constant or a constant expression.
Parameter 3: Set the lower threshold level. Enter a constant or a constant expression.
PWHH(C1,K1,K2) Compute the pulse width of waveform C1 with Upper set to K1 and
Lower set to K2
DUTYH(C2,P.High(C2),P.
Low(C2))
Compute the pulse width of waveform C2 with Upper set to
waveform C2’s high value and Lower set to waveform C2’s low value
PWHH(5,10,2) Not allowed because parameter 1 is not a waveform
PWHL(C1,C2,−1) Not allowed because parameter 2 is not a constant or a constant
expression
PWLL(C1+C2,1,−1) Not allowed because parameter 1 is not a single-term waveform
DA (D/A Conversion) Examples
Syntax: DA(parameter 1)
Parameter 1: Set the source waveform for DA computation. This can be set only for C4. This can be
executed only when the LOGIC menu key is illuminated.
DA(C4) D/A conversion of a logic waveform
Examples of Other Operators
Syntax: Operator(parameter)
Parameter: Specify a waveform, a constant, or an expression.
SIN(PI) Example in which the parameter is set to a constant
COS(C1) Example in which the parameter is set to a waveform
ABS(C1+C2
*
2) Example in which the parameter is set to an expression that consists of
waveforms and a constant
SQRT(ABS(C1+C2
*
2)) Example in which the parameter is set to an expression
SIN(2
*
PI
*
T
*
K1) Example in which the parameters is set to an expression (that consists
of elapsed time T and constants)
9 Computed and Reference Waveforms
