22-10
IM DLM3054-01EN
Self-Test (Self Test)
You can test the keyboard and memory operations.
Test Type (Type)
You can perform the following tests.
Memory Test (Memory)
Tests whether or not the internal CPU board RAM and ROM are operating properly. If they are operating
properly, “Success” appears. If an error occurs, “Fail” appears.
Keyboard Test (Keyboard)
Tests whether the front panel keys and knobs are operating correctly and whether the soft keyboard accepts
input properly.
• The front panel keys are operating properly if the background color of the names of the keys that you press
turns white or green.
• Knobs are operating properly if you turn them slowly, press them, or tilt them depending on the type of knob
and the background color of the names or arrows changes to white or green.
• The soft keyboard is operating properly if you can enter the specified characters.
Printer Test (Printer)
Tests whether or not the optional built-in printer is operating properly. The built-in printer is operating properly if
the print density is correct. If an error occurs, the print density will not be correct.
Accuracy is a service test item. Under normal circumstances, you do not need to perform these tests.
Executing a Test (Test Exec)
The selected self-test starts.
If an Error Occurs during a Self-Test
If an error occurs even after you carry out the following procedure, contact your nearest YOKOGAWA dealer.
• Execute the self-test again several times.
• Confirm whether or not the media being tested is properly inserted.
• Check that the paper is set properly in the built-in printer and that paper is not jammed.
Touch Panel (TOUCH)
Turns the touch panel feature on and off. When the touch panel feature is on, the indicator illuminates.
For the operating procedure, see the Getting Started Guide, IM DLM3054-03EN.
22 Other Features
To Next Page
