YOKOGAWA DLM3024 User Manual

15-3
IM DLM3054-01EN
Detected Point Number (Pattern No.)
Specify the number of the detected point (the location where the search condition was met) you want to display
in the zoom window.
Detected points are numbered in order. The first detected point is zero.
The maximum detected point number is 50000.
Zoom Position (Z1 Position, Z2 Position)
You can change the zoom position in the zoom window that is specified using Result Window in the menu
accessible with the Search soft key. You can also link the analysis number (List No.) and zoom position settings.
Decoded Display (Decode)
The instrument decodes each field value and displays the decoded result using different colors for each field at
the bottom of the screen.
The following table shows the available decode display formats.
Decode Format Hex Dec Bin ASCII Symbol
Serial
bus
FlexRay Yes No Yes No No
CAN Yes No Yes No Yes
*
CAN FD Yes No Yes No Yes
*
LIN Yes No Yes No No
CXPI Yes No Yes No No
SENT Yes Yes No No No
UART Yes No Yes Yes No
I
2
C Yes No Yes Yes No
SPI Yes No Yes Yes No
User Define Yes No Yes Yes No
* You can display the decoded results using symbols by converting a CANdb file (.dbc) to a physical value/
symbol definition file (.sbl) using the free YOKOGAWA conversion software “Symbol Editor” and by loading
the file into the instrument.
Display Example
When Bin display is used, a bit order that is appropriate for the displayed waveforms is used regardless of the bit
order setting.
The bit order setting varies depending on the bus type.
CRC of FlexRay, CAN, CAN FD, I
2
C, SENT (except when the data type is User) MSB
Data of LIN, CXPI LSB
UART, SPI, SENT (when the data type is User) LSB or MSB
Binary display
Hexadecimal display (bit order: LSB)
Hexadecimal display (bit order: MSB)
0 1 0 1 0 0 1 1
C A
5 3
15 Analyzing and Searching Serial Bus Signals
