19 Printing and Saving Screen Captures

Destination Type (Print To)

You can save screen captures and print them on the following types of printers.

Built-in Printer (BuiltIn)

The optional built-in printer if it is installed.

USB Printer (USB)

The printer that is connected to the instrument through one of the USB 2.0 ports.

Network Printer (Network)

A printer on the network that the instrument is connected to. You must configure the network printer in advance.

File (File)

You can save screen captures to files in PNG, BMP, and JPEG formats.

Multiple Destinations (Multi)

You can perform the following operations at the same time.

• Print and save screen captures to multiple destinations

• Save waveform data to the output destination specified using the file list.

Default Chapter3
