App-14

IM DLM3054-01EN

Appendix 7 Firmware Version and New Features

The following table contains new features that are available for each firmware version. If you are using an older

version, you will not be able to use all the features described in this manual. To view the firmware version,

press the Overview soft key on the UTILITY menu and check Firmware Version on the Overview screen that is

displayed.

Version Suffix Code New Features Manual Edition Number

1.00 and later Standard New 1st Edition
