Signal Type and Trigger Type Combinations
The signal type (analog or logic) determines what trigger types you can use.
CH1 to CH4 LOGIC Mixed
Edge Yes Yes −
Edge OR Yes No No
Pattern Yes Yes Yes
Pulse Width Yes Yes −
Rise/Fall Time Yes No −
Runt Yes No −
Timeout Yes Yes −
Window Yes No −
Window OR Yes No No
Interval Yes Yes −
Serial FlexRay Yes No −
CAN Yes No −
CAN FD Yes No −
LIN Yes No −
CXPI Yes No −
SENT Yes Yes −
UART Yes Yes −
I2C Yes Yes Yes
SPI Yes Yes Yes
User Define Yes No No
TV Yes No −
• CH4 and LOGIC cannot be used simultaneously in waveform display, measurement, analysis, or search,
but they can be used simultaneously as trigger sources in triggering.
• When the maximum record length is in use, CH2, CH4, and LOGIC cannot acquire waveforms, but they
can be used as trigger sources.
4 Triggering
