20-1
IM DLM3054-01EN
20 Saving and Loading Data
You can save the following types of data to the internal storage, a USB storage device, or a network drive.
• Waveform data
• Setup data
• Screen capture data
• Waveform zone data
• Snapshot waveform data
• Automated measurement data
• Serial bus analysis results
• FFT waveform data
• Histogram data
• List of Timestamps data
You can load the following types of data from a storage device into the instrument’s internal storage.
• Waveform data
• Setup data
• Waveform zone and polygonal zone data
• Snapshot waveform data
• Physical value/symbol definition files
You can also rename and copy files and set or clear protection on files.
Storage Device You Can Save and Load From
This instrument can access the following three types of storage devices for saving and loading data.
Internal storage (Flash_Mem)
The internal storage of this instrument. For the memory size, see section 6.7 in the Getting Started Guide (IM
DLM3054-03EN).
USB Storage Device (USB/USB1)
A USB storage device that is connected to the instrument’s USB port. USB2.0 mass storage devices compatible
with USB Mass Storage Class Ver. 1.1 can be connected to the instrument.
Network Drive (Network)
A storage device on the network. If a Ethernet port is available, you can connect the instrument to an Ethernet
network and use a network drive.
• Only connect a compatible USB keyboard, mouse, printer, or storage device to the USB port for
peripherals.
• Do not connect and disconnect multiple USB devices repetitively. Provide at least a 10-second interval
between removal and connection.
• Do not connect or remove USB cables from the time when the instrument is turned on until key operation
becomes available (approximately 20 to 30 seconds).
• You can use USB storage devices that are compatible with USB Mass Storage Class version 1.1.
• The instrument can handle up to two storage devices. If the connected medium is partitioned, the
instrument treats each partition as a separate storage device. As such, the instrument can handle up to two
partitions.
To Next Page
