12-13
IM DLM3054-01EN
fs Sample rate. The instrument’s sample rate when the computation was
executed.
The value changes according to the changes in the T/div or record length
setting.
Measure Item Max(C1) Selects a waveform parameter.
A2 PP(C1,A2) Specifies the calculation source area. If you want to calculate on Area2, add
“,A2” after the calculation source channel.
Unit (Unit)
You can set the unit, which is used when the computed results are displayed, using up to four characters.
Notes about Automated Measurement of Waveform Parameters
• When an item is impossible to measure its measured value is displayed as ‘*****’.
• The instrument may not measure correctly if the waveform amplitude is small.
• To stop automated measurement, select OFF by pressing MEASURE > Mode soft key. Measurement stops
immediately.
• Notes about Statistical Processing
If the statistical processing mode is set to Cycle or History, all keys and soft keys except the Abort soft key are
invalid during statistical processing. In Continuous mode, the RUN/STOP key and TrigLevelChange Soft key
are valid.
12 Automated Measurement of Waveform Parameters
