YOKOGAWA DLM3024 User Manual

11-5
IM DLM3054-01EN
Notes about Cursor Measurement
• The measured time values are based on the trigger position.*
* If delay cancel (Delay Cancel) is set to OFF, they are based on the trigger point.
• The measured value for data that cannot be measured appears as “***.”
• If the display record length is less than a given length (in the interpolation zone), the instrument interpolates
between sampled data if Dot Connect is not set to OFF. Therefore, it is possible for there to be no sampled
data where the vertical cursor is.
Because marker cursors move on the sampled data, you can always read sampled data.
Cursor Jumping (Cursor Jump/T Cursor Jump)
You can make Cursor1, Cursor2, or Marker1 to Marker4 jump to the center of the specified zoom window. The
jump options are listed below.
When the cursor is ΔT, the ΔT&ΔV ΔT cursor, or Degree
Cursor1 to Zoom1: Cursor1 jumps to the Zoom1 window. Cursor1 to
Cursor1 to Zoom2: Cursor1 jumps to the Zoom2 window. Cursor1 to
Cursor2 to Zoom1: Cursor2 jumps to the Zoom1 window. Cursor1 to
Cursor2 to Zoom2: Cursor2 jumps to the Zoom2 window. Cursor1 to
For marker cursors
Jump to Zoom1: The selected marker jumps to the Zoom1 window.
Jump to Zoom2: The selected marker jumps to the Zoom2 window.
11 Cursor Measurement
