List Display (List)
The list displays the following items.
No. Analysis number. Negative numbers are assigned to frames before the and positive
numbers are assigned to frames after the trigger position.*
The instrument can display the analysis results for up to 100000 frames in the range of
−99999 to 99999. Pressing the RESET key highlights frame number zero.
Time(ms) Displays the time from the trigger position* to the start of the frame in milliseconds.
ID Displays the ID value in hexadecimal notation.
ID−Field Displays the ID value including the 2-bit parity in hexadecimal notation.
Data Displays the data in hexadecimal notation.
Checksum Displays the checksum value in hexadecimal notation.
Information Detects and displays the following signals and errors. If a WakeUp signal is detected, the
instrument displays “WakeUp.” If multiple errors are detected in one frame, the instrument
displays the error with the highest precedence. The errors are listed below in order of
precedence with the highest precedence error first.
Timeout-Error, Framing-Error, Checksum-Error, Synch-Field-Error, ID-Parity-Error
* If delay cancel (Delay Cancel) is set to OFF, they are based on the trigger point.
Search Setup (Search)
Search Type (Mode)
Select the LIN bus signal search type from one of the settings below.
• Break Synch: Searches for break and synch fields
• Error: Searches for errors
• ID/Data: Searches for both the ID bit pattern and Data pattern (AND)
The method of setting Break Synch and ID/Data is the same as that of setting the LIN bus trigger conditions.
However, you cannot specify the break length as a search condition.
