Auto Setup (Auto Setup)
Executes auto setup based on the specified sources.
The auto setup feature automatically configures the bit rate, level, and hysteresis and triggers on the start of
frame (SOF) of the CXPI bus signal. You cannot execute auto setup if the source is set to Math1 to Math4.
Decoded Display (Decode)
The colors that are used for the fields in the decoded display are as follows:
PTYPE Pink (Pink)
ID Light green (Light Green)
DLC, extension
DLC*
Pink (Pink)
CT Orange (Orange)
NM(Sleep.ind/
Wakeup.ind)
Yellow (Yellow)
Data Cyan (Cyan)
CRC Light blue (Light Blue)
Parity Yellow (Yellow)
Start Bit Gray (Gray) fill
Stop Bit Gray (Gray) fill
IBS Gray (Gray) fill
Wakeup pulse Green (Green)
Error Red (Red)
Parity Error, CRC Error, Counter (CT) Error:
Characters in the parity, CRC, or CT field in which an error occurred are displayed in
black on a red background.
Data Length Error:
When the data length is less than DLC, characters in the DLC field is displayed in black
on a red background.
When the data length is greater than DLC, characters in the exceeded field is displayed in
black on a red background.
Framing Error:
“Framing Error” is displayed in black on a red background in the field after the error
occurrence.
IBS Error:
“IBS Error” is displayed in black on a red background in the IBS field.
Clock Error:
“• • •” is displayed in black on a red background in the field that the error occurred in.
*
Extension DLC applies to long frames.
