15-22
IM DLM3054-01EN
If the comparison condition is a ≤ Data ≤ b or “Data < a or b < Data,” the two reference values are
automatically adjusted so that the lower limit is less than or equal to the upper limit.
Byte Order (Endian), Sign (Sign), and Comparison Range (MSB/LSB)
These items are the same as those of the CAN bus trigger.
Wakeup/Sleep
The instrument searches for wakeup pulses, wakeup states, sleep frames, or sleep states.
• Wakeup/Sleep Type OR
Wakeup Pulse When a pulse in the dominant period between 250 μs and 2500 μs is detected
Wakeup When a transition from a state in which there is no clock after a sleep detection to a state
in which there is a clock is detected
Sleep Frame When the sleep frame ID value is 1F (hexadecimal)
Sleep When 5 ms elapses after a transition is made from a state in which there is a clock to a
state in which there is no clock
Executing a Search (Search)
The instrument searches for locations where the specified search conditions are met. Then, the instrument
displays the specified detected point number (Pattern No) expanded in the zoom window.
Detected Points
The detected points are the same as the trigger points.
15 Analyzing and Searching Serial Bus Signals
To Next Page
