YOKOGAWA DLM3024 User Manual

20-9
IM DLM3054-01EN
CAN, CAN FD
You can save analysis results of CAN or CAN FD bus signals to a file in CSV format. The extension is .csv.
Analysis results of up to 100000 frames (50000 frames for CAN FD) can be saved.
Data size*
CAN: (The number of frames in analysis results + 4) × 125 bytes
CAN FD: (The number of frames in analysis results + 4) × 300 bytes
* The data size is for reference. It is not strictly warranted. Use this as reference for saving data.
CAN Output Example
ID in hexadecimal
ACK slot state
Y: ACK present
N: ACK not present
Amount of time from the trigger
position to the start of frame
Frame type
Analysis number
DLC in hexadecimal
Data in hexadecimal
CRC sequence in
hexadecimal
Analysis Type SerialBus(CAN)
Model Name DLM3000
Model Version *.**
No. Time(ms) Frame ID DLC Data CRC Ack Information
-8 -17.5848 Data 00A 2 1 0
-7 -17.2968 Error
-6 -15.0728 Data 00A 2 01 02 4A24 Y
-5 -12.5608 Data 12 1 FE 2263 Y
-4 -10.1204 Data 100 3 FF 01 A4 6C6E Y
-3 -7.5364 Data 00A 2 01 02 4A24 Y
-2 -5.0244 Data 12 1 FE 2263 Y
-1 -2.5844 Data 100 3 FF 01 A4 6C6E Y
0 -0.0004 Data 00A 2 01 02 4A24 Y
1 2.5116 Data 12 1 FE 2263 Y
2 4.9516 Data 100 3 FF 01 A4 6C6E Y
3 7.5356 Data 00A 2 01 02 4A24 Y
CAN FD Output Example
ID in hexadecimal
ACK slot state
Y: ACK present
N: ACK not present
Error information
Stuff Error
Fixed Stuff Error
CRC Error(SC;Seq)
ESI(Error Passive)
etc.
Amount of time from the trigger position
to the start of frame
Frame type
(“Data” is displayed for CAN.)
Analysis number
DLC in hexadecimal
Data in hexadecimal
CRC sequence in hexadecimal
When the CAN FD standard is set to
ISO, the stuff count is displayed in
hexadecimal notation.
Analysis Type SerialBus(CAN FD:ISO)
Model Name DLM3000
Model Version *.**
No. Time(ms) Frame ID DLC Data SC
CRC Ack Information
-5 -2.137288 FD Data 1FFFFFFF 4 FF FF FF FF C 11606 Y CRC Error(Seq)
-4 -2.034984 Error
-3 -1.943288 FD Data 15555555 8 55 AA C3 0F 55 AA C3 0F 0 19B09F Y
-2 -1.71728 FD Data 0AAAAAAA 8 AA 55 3C F0 AA 55 3C F0 0 005ED1 Y
-1 -1.00528 FD Data 78 2 0F 0F A 00C18 Y
0 -0.19673 FD Data 01E38000 1 7 9 1592F Y ESI(Error Passive)
1 1.050728 FD Data 101 0 3 1417A Y
2 1.200728 FD Data 102 0 C 0EADE Y
3 1.650736 FD Data 104 1 8 6 312 N
4 2.006736 Data 0 8 00 00 00 00 00 00 00 00 145B Y
“CAN FD:ISO” is displayed when the CAN FD standard is set to ISO.
“CAN FD:non-ISO” is displayed when the CAN FD standard is set to non-ISO.
20 Saving and Loading Data
