22-5
IM DLM3054-01EN
GP-IB
Connects the instrument to a PC using GP-IB.
Address (Address)
• You can select a value between 0 and 30.
• Each device that is connected in a GP-IB system has its own unique address. This address is used to
distinguish between different devices. Therefore, you must assign a unique address to the instrument when
connecting it to a PC or other device.
When the controller is communicating with the instrument or with other devices through GP-IB, do not change
the address.
Notes about Connections
• Multiple cables can be used to connect multiple devices. However, no more than 15 devices, including the
controller, can be connected on a single bus.
• When connecting multiple devices, you must assign a unique address to each device.
• Use cables that are 2 m or shorter in length to connect devices.
• Make sure the total length of all cables does not exceed 20 m.
• When devices are communicating, have at least two-thirds of the devices on the bus turned on.
• To connect multiple devices, use a star or daisy-chain configuration. Loop and parallel configurations are
not allowed.
Network (Network)
Connects this Instrument to a PC using Ethernet.
VXI-11(VXI-11)
Select whether to allow access to the instrument using VXI-11.
• ON: Allows access
• OFF: Denies access
Socket Interface (Socket)
Select whether to allow access to the instrument using the socket interface.
• ON: Allows access
• OFF: Denies access
Timeout (Timeout)
If a connection cannot be established between the instrument and the PC within the amount of time specified
here, the instrument aborts the connection process.
Selectable range: 1 s to 3600 s, Infinite
You must set TCP/IP parameters to connect this Instrument to an Ethernet network.
Notes about Connections
• To connect the instrument to a PC, be sure to use straight cables and to connect through a hub or router.
Proper operation is not guaranteed for a one-to-one connection using a crossover cable.
• Use one of the following types of network cable that conforms to the transfer speed of your network.
A UTP (Unshielded Twisted-Pair) cable
An STP (Shielded Twisted-Pair) cable
22 Other Features
To Next Page
