YOKOGAWA DLM3024 User Manual

4-12
IM DLM3054-01EN
Combination (Logic)
Select the trigger source combination from one of the settings below.
AND Allows triggering when all the trigger source signal patterns match the specified pattern
OR Allows triggering when any of the trigger source signal patterns matches the specified pattern
Trigger Condition (Condition)
Select the condition for judging the results of comparing the trigger source signal pattern and the specified
pattern.
With a Clock Source
Enter Detects changes in the comparison results from a mismatched condition to a matched condition
at the clock source sampling timing. The instrument triggers at the point of change.
Exit Detects changes in the comparison results from a matched condition to a mismatched condition
at the clock source sampling timing. The instrument triggers at the point of change.
True Detects matches in the comparison results. The instrument triggers at the clock source
sampling points while the match is true.
False Detects mismatches in the comparison results. The instrument triggers at the clock source
sampling points while the mismatch is true.
Without a Clock Source
Enter Detects changes in the comparison results from a mismatched condition to a matched
condition. The instrument triggers at the point of change.
Exit Detects changes in the comparison results from a matched condition to a mismatched
condition. The instrument triggers at the point of change.
True Detects matches in the comparison conditions. The trigger timing varies depending on time
conditions, explained later.
False Detects mismatches in the comparison conditions. The trigger timing varies depending on time
conditions, explained later.
Time Condition (Time Qualification)
Set what kind of relationship must be established between the trigger condition achievement time and the
specified reference time (Time, Time1, Time2). You can set this when the clock source is set to None and the
trigger condition (Condition) is true or false.
More than When the trigger condition achievement time (t) is longer than the specified reference time (Time)
Less than When the trigger condition achievement time (t) is shorter than the specified reference time
(Time)
Inside When the trigger condition achievement time (t) is longer than reference time Time1 and
shorter than reference time Time2.
Outside When the trigger condition achievement time (t) is longer than reference time Time1 and
shorter than reference time or Time2
Timeout When the trigger condition achievement time (t) is longer than the specified reference time (Time)
Reference Times (Time or Time1 and Time2)
The selectable range for Time or Time1 and Time2 varies depending on the time condition. You can set this
when the clock source is set to None and the trigger condition (Condition) is true or false.
More than Time: 2 ns to 10 s
Less than Time: 4 ns to 10 s
Inside Time1: 2 ns to [10 s - 2 ns], Time2: 4 ns to 10 s
Outside Time1: 2 ns to [10 s - 2 ns], Time2: 4 ns to 10 s
Timeout Time: 4 ns to 10 s
Resolution: 2 ns
4 Triggering
