Data Frame
You can specify a value from Data 1 to Data 8 as a trigger condition.
Data Length (Size)
Set how many consecutive data bytes will be compared.
Selectable range: 1 to 8 bytes
Comparison Condition (Condition)
The data trigger condition is met when the relationship between the data pattern or the reference value and
the input signal data value matches the specified comparison condition.
True When the value matches the data pattern
False When the value does not match the data pattern
Data=a
1
When the value is equal to the reference value
Data≠a
1
When the value is not equal to the reference value
a≤Data
1
When the value is greater than or equal to the reference value
Data≤b
1
When the value is less than or equal to the reference value
a≤Data≤b
2
When the value is within the reference range (including the reference values)
Data<a, b<Data
2
When the value is outside the reference range (excluding the reference values)
1 Set one reference value
2 Set two reference values
Data Pattern (Hex/Bin)
If the comparison condition is set to True or False, set the data pattern for the specified data size in
hexadecimal (Hex) or binary (Bin) notation.
Reference Values (a and b)
If the comparison condition is set to Data = A, Data ≠ a, a ≤ Data, Data ≤ b, a ≤ Data ≤ b, or “Data < a or
b < Data,” set the reference values in decimal notation. You must set the byte order (Endian), sign (Sign),
and comparison range (MSB or LSB). The selectable ranges are as follows:
Unsigned
(Unsign)
0 to 9E+18
The selectable maximum value is limited by the data length
and bit position, which are determined by the Data Size and
MSB/ LSB settings, respectively.
Signed
(Sign)
−9E+18 to 9E+18
The selectable minimum and maximum values are limited by
the data length and bit position, which are determined by the
Data Size and MSB/ LSB settings, respectively.
The value is displayed in scientific notation when the number of digits exceed seven (example:
1234567E+10).
If the comparison condition is a ≤ Data ≤ b or “Data < a or b < Data,” the two reference values are
automatically adjusted so that the lower limit is less than or equal to the upper limit.
Byte Order (Endian)
Set the data byte order to big endian (Big) or little endian (Little).
Sign (Sign)
Set whether to use a signed (Sign) or unsigned (Unsign) data format.
The selectable range of data reference values varies depending on whether the data is signed or unsigned.
Comparison Range (MSB/LSB)
Set the MSB (MSB) or LSB (LSB) bit positions for the data that you will compare.
Selectable range: 0 to (the number of bytes of data × 8 − 1). The maximum value is 63.
4 Triggering
