CANbus communication does not work properly. The hexadecimal value “XX”
identifies the faulty node.
Troubleshooting
Verify the CANbus network (external issue).
Replace the logic board (internal issue).
INT CANBUSKO (MDI/LED code = 67)
Cause
Internal CANbus communication between the two uC does not work properly.
Troubleshooting
Replace the logic board (internal issue).
OFFSET SPD.SENS. (MDI/LED code = 3)
Cause:
It is necessary to acquire the offset angle between the stator and the speed
sensor, i.e. they mutual angular misalignment. An automatic function is dedicated
to this procedure.
Troubleshooting:
Perform the teaching procedure: in OPTIONS, select ABS SENS. ACQUIRE. See
paragraph Errore. L'origine riferimento non è stata trovata. for more details.
OPEN COIL EV. XX (MDI/LED code = 21)
Cause:
This fault appears when no load is connected between one or more EV outputs
and the positive terminal PEV (pin A24)
Alarm not present for DualACE2
Troubleshooting:
Check the coils.
Check the wiring.
If the problem is not solved, replace the logic board.
OVERLOAD (MDI/LED code = 57)
Cause
The motor current has overcome the limit fixed by hardware.
Troubleshooting
If the alarm condition occurs again, ask for assistance to a Zapi technician. The
fault condition could be affected by wrong adjustments of motor parameters.
PARAM RESTORE (MDI/LED code = 14)
Cause:
The controller has restored the default settings. If a CLEAR EEPROM has been
made before the last key re-cycle, this warning informs you that EEPROM was
correctly cleared.
Troubleshooting:
A travel demand or a pump request does cancel the alarm.
If the alarm appears at key-on without any CLEAR EEPROM performed, replace
the controller.
PARAM TRANSFER (MDI/LED code = 93)
