DUALBLE2 NEW GENERATION with sin/cos sensors
Pin
Type
Name
Description
A19
Input
SPARE
Digital input, active when connected to -B.
The default function is not defined.
A20
Input
SPARE
Digital input, active when connected to -B.
The default function is not defined.
A21
Output
NSENS_R
Negative supply for the right-hand side sin/cos sensor, the
right-hand side thermal sensor and potentiometers.
A22
Input
COS_R
Cosine signal of the right-hand side sin/cos sensor.
A34
Input
SIN_L
Sine signal of the left-hand side sin/cos sensor.
A35
Input
COS_L
Cosine signal of the left-hand side sin/cos sensor.
4.2.6 Dual BL traction with Hall sensors
When the inverter is configured as DUALBLE2 NEW GENERATION for
controlling two traction brushless motors, each one equipped with a set of three
Hall sensors as speed and position feedback, the pinout differs from that of the
dual AC traction configuration only for the pins listed in the following table. The
other ones are unchanged both in name and in function (see paragraph 4.2.3).
DUALBLE2 NEW GENERATION with Hall sensors
Pin
Type
Name
Description
A2
Input
SH1_L
First left-hand side Hall sensor.
A4
Output
PSENS_L
Positive supply for the left-hand side Hall sensors and for
potentiometers (+5 V or +12 V, 200 mA maximum).
A9
Input
SH2_R
Second right-hand side Hall sensor.
A10
Output
PSENS_R
Positive supply for the right-hand side sensor and for
potentiometers (+5 V or +12 V, 200 mA maximum).
A12
Input
SH1_R
First right-hand side Hall sensor.
A15
Output
NSENS_L
Negative supply for the left-hand side Hall sensors, the left-
hand side thermal sensor and potentiometers.
A17
Input
SH2_L
Second left-hand side Hall sensor.
