Zapi DUALACE2 NEW GENERATION User Manual

AFNZPxxx– DUALACE2 NEW GENERATION – User Manual Page 107/169
- MIN LOWER
- MAX LOWER
See paragraphs 13.1.5 or 13.2.7 for the acquiring procedure.
9.3 Program STEER function
This enables the adjustment of the minimum and maximum useful signal levels of
the steering control. This function is useful when it is necessary to compensate
for asymmetry with the mechanical elements associated with the steering.
This function looks for and records the minimum, neutral and maximum voltage
over the full mechanical range of the steering. It allows to compensate for
dissymmetry of the mechanical system in both directions.
The values to be acquired are organized in the ADJUSTMENT list, they are:
- STEER RIGHT VOLT
- STEER LEFT VOLT
- STEER ZERO VOLT
See paragraphs 13.1.6 or 13.2.8 for acquiring procedure.
