Zapi DUALACE2 NEW GENERATION User Manual

AFNZPxxx– DUALACE2 NEW GENERATION – User Manual Page 77/169
PARAMETER PUMP
Parameter
Allowable range
Description
P THROTTLE X1 MAP
(C)
0% ÷ 100%
(steps of 1%)
This parameter defines the lift potentiometer curve.
See paragraph 9.9.
P THROTTLE Y1 MAP
(C)
0% ÷ 100%
(steps of 1%)
This parameter defines the lift potentiometer curve.
See paragraph 9.9.
P THROTTLE X2 MAP
(C)
0% ÷ 100%
(steps of 1%)
This parameter defines the lift potentiometer curve.
See paragraph 9.9.
P THROTTLE Y2 MAP
(C)
0% ÷ 100%
(steps of 1%)
This parameter defines the lift potentiometer curve.
See paragraph 9.9.
P THROTTLE X3 MAP
(C)
0% ÷ 100%
(steps of 1%)
This parameter defines the lift potentiometer curve.
See paragraph 9.9.
P THROTTLE Y3 MAP
(C)
0% ÷ 100%
(steps of 1%)
This parameter defines lift potentiometer curve.
See paragraph 9.9.
8.2.4 Set Option
SET OPTIONS
Parameter
Allowable range
Description
HM DISPLAY OPT.
(D, C)
0 ÷ 6
This parameter defines the configuration for the hour meter
shown on a display (i.e. MDI). The possible settings are the
same described for parameter HM CUSTOM 1 OPT..
HM CUSTOM 1 OPT.
(A)
0 ÷ 6
This parameter decides the configuration for the hour meter
number 1 accessible to the customer.
The possible settings are:
0: The hour meter counts since the controller is on.
1: The hour meter counts when the three-phase
power bridge is active.
2: Not used in ACE2 NEW GENERATION.
3: The hour meter counts when one of the valve
outputs is active.
4: Not used in ACE2 NEW GENERATION.
5: The hour meter counts when one of the valve
outputs is active.
6: Not used in ACE2 NEW GENERATION.
HM CUSTOM 2 OPT.
(A)
0 ÷ 6
This parameter decides the configuration for the hour meter
number 2 accessible to the customer. The possible settings
are the same of HM CUSTOM 1 OPT. parameter.
