Zapi DUALACE2 NEW GENERATION User Manual

AFNZPxxx– DUALACE2 NEW GENERATION – User Manual Page 95/169
8.2.8 SLV HW Setting
HARDWARE SETTING
Parameter
Allowable range
Description
S FEEDBACK SENS.
(A)
0 ÷ 6
This parameter defines the type of the adopted speed
sensor for motor 2. Factory adjusted.
0 = Incremental encoder.
1 = Sin/cos sensor.
2 = Incremental encoder + sin/cos sensor.
3 = Incremental encoder + sin/cos sensor + index.
4 = PWM absolute sensor + incremental encoder +
index.
5 = Resolver.
6 = Hall effect sensor (six-step).
S ROT. CW ENC
(A)
OPTION#1 ÷ OPTION#2
It defines how the signal sequence coming from the
encoder channels is expected by controller 2
OPTION#1 = Channel A anticipates channel B.
OPTION#2 = Channel B anticipates channel A.
S ROT CW MOT
(A)
OPTION#1 ÷ OPTION#2
It permits to change the sequence in which the motor 2
phases are powered. Factory adjusted.
OPTION#1 = U-V-W corresponds to forward direction.
OPTION#2 = V-U-W corresponds to forward direction.
S ENC PULSES 1
(A)
32 ÷ 1024
This parameter defines the number of encoder pulses per
revolution (motor 2). It must be set equal to ENCODER
PULSES 2; otherwise the controller raises an alarm.
The available options are:
25
32
48
64
80
124
128
256
512
1024
NOTE: with standard HW, the capability to use encoders
with high number of pulses could be limited depending on
the speed. Ask to Zapi technician before to operate on this
parameter
