8.2.5 Adjustments
This parameter must be set to the nominal battery voltage.
The available options are:
24V, 36V, 48V, 72V, 80V
Fine adjustment of the key voltage measured by the
controller. Calibrated by Zapi production department during
the end of line test.
Fine adjustment of the battery voltage measured by the
controller. Calibrated by Zapi production department during
the end of line test.
This parameter defines the supply-voltage value
connected to PEBA27 (A17). Available values are:
12V, 24V, 36V, 40V, 48V, 72V, 80V
0 V ÷ 25.5 V
(steps of 0.1 V)
It records the minimum value of brake potentiometer when
the brake is analog.
0 V ÷ 25.5 V
(steps of 0.1V)
It records the maximum value of brake potentiometer when
the brake is analog.
MIN LIFT
(Read Only)
(D, C)
0 V ÷ 25.5 V
(steps of 0.1V)
It records the minimum value of lower potentiometer when
the lower switch is closed.
See paragraph 9.2.
MAX LIFT
(Read Only)
(D, C)
0 V ÷ 25.5 V
(steps of 0.1V)
It records the maximum value of lower potentiometer when
the lower switch is closed.
See paragraph 9.2.
MIN LOWER
(Read Only)
(D, C)
0 V ÷ 25.5 V
(steps of 0.1V)
It records the minimum value of lower potentiometer when
the lower switch is closed.
See paragraph 9.2.
MAX LOWER
(Read Only)
(D, C)
0 V ÷ 25.5 V
(steps of 0.1V)
It records the maximum value of lower potentiometer when
the lower switch is closed.
See paragraph 9.2.
This parameter defines a dead band in the accelerator
input curve.
See paragraph 9.9.
This parameter defines the accelerator input curve.
See paragraph 9.9.
This parameter defines the accelerator input curve.
See paragraph 9.9.
