 Upon request controller can be configured having different current rating for the
two power section
2.4 Voltage ratings
Nominal DC voltage
24 V
36 V / 48 V
72 V / 80 V
96 V
Conventional working voltage range
19.2V÷28.8V
28.8V÷57.6V
57.6V÷96V
76.8V÷115.2V
Non-operational overvoltage limits
35 V
72.5 V
115 V
130 V
Non-operational undervoltage limits
10 V
10 V
30 V
30 V
 Conventionally, the controller can be set to operate without alarm in the range
from 80% to 120% of the nominal battery voltage. With a different DC voltage
than specified, the controller raises an alarm.
 Undervoltage and overvoltage thresholds are defined by hardware. After start-up,
controller is fully operative if the supply voltage stays within these limits.
 Undervoltage is evaluated on the KEY input (A3); overvoltage is evaluated on the
positive battery terminal +B.
