AFNZPxxx DUALACE2 NEW GENERATION User Manual Page 35/169
DUALACE2 NEW GENERATION (dual traction)
Pin
Type
Name
Description
A33
Input
PTH_L
Analog input for the thermal sensor of the left-hand side
traction motor.
Internal pull-up is a 2 mA current source (max 5 V).
A34
Input
CPOT5
Analog input 5.
The default function is not defined.
A35
Input
CPOT6
Analog input 6.
The default function is not defined.
4.2.4 Combi AC configuration (traction + pump)
When the inverter is configured as COMBIACE2 NEW GENERATION for
controlling one traction motor and one pump motor, the pinout differs from that of
the dual traction configuration only for the pins listed in the following table. The
other ones are unchanged both in name and in function (see paragraph 4.2.3).
COMBIACE2 NEW GENERATION (traction + pump)
Pin
Type
Name
Description
A2
Input
SR/HB/
HYDRO
Digital input, inactive when connected to -B, active when the
switch is open.
The default function is as hydro request.
A4
Output
PENC_P
Positive supply for the pump encoder and for potentiometers
(+5 V or +12 V, 200 mA maximum).
A9
Input
CHA_T
Channel A of the traction incremental encoder.
A10
Output
PENC_T
Positive supply for the traction encoder and for potentiometers
(+5 V or +12 V, 200 mA maximum).
A12
Input
LIFT
Digital input, active when connected to -B.
The default function is as lift request; closing this input the
pump is activated.
A15
Output
NENC_P
Negative supply for the pump encoder, the pump thermal
sensor and potentiometers.
A17
Input
CHA_P
Channel A of the left-hand side incremental encoder.
A19
Input
CHB_P
Channel B of the pump incremental encoder.
A20
Input
CHB_T
Channel B of the traction incremental encoder.
