92 Z4Mplus and Z6Mplus User Guide
Routine Care and Adjustments
Cleaning Procedures
Clean the Peel-Off Assembly
The Peel-Off option is required.
Refer to the illustration on the previous page and perform the
following procedure if adhesive buildup begins to affect peel-
off performance.
1. Open the printhead assembly.
2. Close the peel assembly to prevent bending the tear-off/peel-off bar during
cleaning. Using the Preventive Maintenance Kit (Zebra part number 47362) or a
solution of 90% Isopropyl and 10% deionized water and a swab, remove excess
adhesive from the tear-off/peel-off bar.
3. Open the peel assembly by pivoting the module toward you.
4. Manually rotate the pinch roller and clean thoroughly with solvent and a swab.
5. Close the peel assembly.
6. Close the printhead assembly.
Caution • Ensure printhead is fully open and engaged in the up position. Failure to
latch in the up position could result in the printhead falling on your hand during the
procedure.
Note • Apply minimum force when cleaning the tear-off/peel-off bar. Excessive
force can cause the tear-off/peel-off bar to bend, which could have a negative effect
on peel performance.
Note • When cleaning the tear-off/peel-off bar or the pinch roller, remove excess
solvent with a pad to ensure the solvent has dried before printing.

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
