Zebra Z4Mplus User Manual

118 Z4Mplus and Z6Mplus User Guide
Specifications
Ribbon Specifications
Ribbon Specifications
Ribbon Specifications Z4Mplus Z6Mplus
Ribbon must be wound with the coated side out
Ribbon width
(Zebra recommends using ribbon at least
as wide as the media to protect the
printhead from wear.)
Minimum >1 in. 25.4 mm >2 in. 60 mm
Maximum 4.3 in. 109 mm 6.9 in. 174 mm
Standard lengths 2:1 media to
ribbon roll
ratio
984 ft. 300 m 984 ft. 300 m
3:1 media to
ribbon roll
ratio
1476 ft. 450 m 1476 ft. 450 m
Ribbon core inside diameter 1 in. 25.4 mm 1 in. 25.4 mm

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
