114 Z4Mplus and Z6Mplus User Guide
Specifications
General Specifications
General Specifications
General
Specifications
Z4Mplus Z6Mplus
Height 13.3 in. 338 mm 13.3 in. 338 mm
Width 10.9 in. 277 mm 13.4 in. 341 mm
Depth 18.7 in. 475 mm 18.7 in. 475 mm
Weight (without options) 32.4 lbs. 14.7 kg 34.7 lbs. 16 kg
Electrical 90-265 VAC, 48-62 Hz, 5 Amps
(fused)
90-265 VAC, 48-62 Hz, 5 Amps
(fused)
Agency Approvals UL 1950, CISPR 22 (class B), CSA 22.2 No. 950-95, IEC60950,
EN60950, EN500824, EN55022 (class B), EN55024, EN61000-3-2, -3-3.
Complies with FCC Class B and Canadian Doc Class A rules. Carries the
CE mark of compliance. Product markings: cULus, CE Marking, FCC-B,
ICES-003, VCCI, C-Tick, NOM, IRAM, CCC, GOST-R, BSMI.
Temperature Operating 40° to 104°F 5° to 40°C 40° to 104°F 5° to 40° C
Storage –40° to 140°F –40° to 60°C –40° to 140°F –40° to 60°C
Relative
Humidity
Operating 20% to 85%, non-condensing 20% to 85%, non-condensing
Storage 5% to 85%, non-condensing 5% to 85%, non-condensing
Communication Interface RS-232/CCITT V.24 serial data interface; 110 to115000 baud, parity, bits/
character, 7 or 8 data bit, and XON-XOFF, RTS/CTS or DTR/DSR
handshake protocol required. 750mA at 5 V from pin 9.
8-bit parallel data interface; supports IEEE 1284 bi-directional parallel,
ECP and nibble mode compliant. Error detection CRC protocol.

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
