Zebra Z4Mplus User Manual

Configuration
Configuration
Z4Mplus and Z6Mplus User Guide 59
Change Password-Protected Parameters
Certain parameters are password protected by factory default.
1. Enter a four-digit password at the ENTER PASSWORD display.
MINUS (–) changes the selected digit position. PLUS (+) increases the selected
digit value. After entering the password, press SELECT. The parameter you wish
to change is displayed. If the password was entered correctly, you can now change
the value.
2. The default password is 1234. The password can be changed using the ^KP
(Define Password) ZPL II instruction.
Note • You have the option of making all parameters password protected. Refer to
PASSWORD LEVEL on page 81 for details.

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
