Zebra Z4Mplus User Manual

Configuration
Configuration and Calibration Sequence
Z4Mplus and Z6Mplus User Guide 81
PASSWORD LEVEL Press SELECT to make change.
Password Level: Press PLUS (+) or MINUS (–) to display
other choices.
Default: Selected items
Selections: Selected items, all items
Press SELECT to accept the change.
This parameter allows you to select whether certain
Zebra-selected menu items (selected items) or all menu
items (all items) are password protected.
IP RESOLUTION* Press SELECT to make change.
IP Resolution: Press PLUS (+) or MINUS (–) to display
other choices.
Default: Dynamic
Selections: Dynamic, permanent
Press SELECT to accept the change.
Depending on the selection, allows either the user
(permanent) or the server (dynamic) to select the IP address.
For more information, see ZebraNet Networking:
PrintServer II Installation and Users Guide.
IP PROTOCOLS* Press SELECT to make change.
IP Protocols: Press PLUS (+) or MINUS (–) to display
other choices.
Default: All
Selections: All, gleaning only, RARP, BOOTP, DHCP,
DHCP/BOOTP
Press SELECT to accept the change.
If dynamic was chosen in the previous parameter, this
selection determines the method(s) by which the PrintServer
II receives the IP address from the server. For more
information, see ZebraNet Networking: PrintServer II
Installation and Users Guide.
Display Shows Action/Explanation

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
