Zebra Z4Mplus User Manual

Troubleshooting
Print Quality Problems
Z4Mplus and Z6Mplus User Guide 105
Calibration
Problem Solution
Loss of printing registration on
labels. Excessive vertical drift
in top-of-form registration.
Adjust the reflective sensor position. See
page 26.
Set the printer for the correct media type.
See page 63.
Ensure that the media guides are properly
positioned.
Via the front panel, locate the SENSOR
SELECT menu item (page 64) and
manually select the correct sensing
method.
Reload the media. Check the reflective
sensor position (see page 26).
Clean the platen roller according to the
instructions on page 87.
Auto Calibrate failed. Perform a manual calibration
(see page 69).
Reload the media and ensure the reflective
sensor is properly positioned
(see page 26).

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
