Load Media and Ribbon
Load the Media
One method of media loading is shown in the illustration below. For more detailed
instructions, as well as information about how to load the different types of media and
the various printing modes, see Printer Basics on page 33.
Number Description
1
Printhead Assembly
2
Transmissive Sensor
3
Media Supply Guide
4
Media Supply Hanger
5
Dancer
6
Media Guide
7
Printhead Open Lever
1
2
3
4
5
6
7
