Zebra Z4Mplus User Manual

Printer Setup
Printhead Pressure Adjustment
Z4Mplus and Z6Mplus User Guide 17
Set Printhead Pressure
Use the tables below, depending upon which printer you have, to select the initial dial
settings for your media.
Some media types require higher pressure to print well. For these media, increase both
dials one position. If the media tends to shift to the left while printing, increase the
right dial setting one position or decrease the left dial setting one position. If the media
tends to shift to the right while printing, increase the left dial setting one position or
decrease the right dial setting one position.
Z4Mplus
Media Width Left Dial Right Dial
1 in. (25.4 mm) 3 1
2 in. (51 mm) 4 1
3 in. (76 mm) 3 2
3.5 in. and up (89 mm and up) 3 3
Z6Mplus
Media Width Left Dial Right Dial
2 in. (50 mm) 6 1
3 in. (75 mm) 6 2
4 in. (100 mm) 7 3
5 in. (125 mm) 7 4
5.5 in. and up (140 mm and up) 6 6

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
