30 Z4Mplus and Z6Mplus User Guide
Communication
System Considerations
System Considerations
Interfaces
Standard interfaces: the RS-232 DB-9 serial data port, and IEEE 1284 compliant
bi-directional parallel port.
Optional interfaces:
• Socket Card for PCMCIA cards
Optional PrintServers:
• ZebraNet PrintServer II (external)
• PS II Internal PrintServer (factory installed only)
Which enables the printer to be connected to 10Base-T Ethernet networks.
Standard Interfaces
The standard serial and parallel interfaces ar discussed in this section.
Serial Port Communicating using a serial data port (see illustration on next page)
requires choosing the baud rate, number of data bits, stop bits, parity, and handshake
(default settings are 9600 baud, 8 data bits, 1 stop bit, no parity, and XON/XOFF).
Parity only applies to data transmitted by the printer since the parity of received data is
ignored. See Serial Data Communications on page 124 to configure the
Note • For further information on serial and parallel, pin-out, and technical
information, see Appendices A and B, starting on page 123.
Note • For further information on PCMCIA cards, see Appendix C, starting on
page 135
Note • For further information on PrintServer II, see the PrintServer II User and
Reference Guide (Zebra part number 45537L).

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
