Troubleshooting
LCD Error Conditions and Warnings
Z4Mplus and Z6Mplus User Guide 101
Warnings
Warning — HEAD OVER TEMP
Warning — HEAD UNDER TEMP
Caution • The printhead is hot and can cause severe burns. Allow the printhead to
cool.
Problem Solution
The printhead is over
temperature.
Allow the printer to cool. Printing
automatically resumes when the printhead
elements cool to an acceptable operating
temperature.
Caution • The printhead is hot and can cause severe burns. Allow the printhead to
cool.
Problem Solution
The printhead is under
temperature.
Continue printing while the printhead
reaches the correct operating temperature.
The environment may be too cold for
proper printing. Relocate the printer to a
warmer area.

Table of Contents

Other manuals for Zebra Z4Mplus

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Zebra Z4Mplus and is the answer not in the manual?

Zebra Z4Mplus Specifications

General IconGeneral
Print MethodThermal transfer or direct thermal
Resolution203 dpi
Max Print Width4.09 inches
Max Print Length39 inches
Max Print Speed10 inches per second
Memory4 MB Flash, 8 MB DRAM
InterfaceParallel, Serial
Media SensorsReflective and transmissive
Media Width0.79 inches to 4.5 inches
Media Length0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width2 inches to 4.33 inches
Power Requirements100-240 VAC, 50/60 Hz
Operating Temperature40°F to 105°F
Storage Temperature-40 to 140°F (-40 to 60°C)
Humidity20 to 85% non-condensing
