Zebra Z4Mplus User Manual

Specifications
Printing Specifications
Z4Mplus and Z6Mplus User Guide 115
Printing Specifications
Printing Specifications Z4Mplus Z6Mplus
Print resolution 203 dots/inch 8 dots/mm 203 dots/inch 8 dots/mm
300 dots/inch 12 dots/mm 300 dots/inch 12 dots/mm
Dot size
(width x
length)
203 dpi 0.00492 in. x
0.00492 in.
0.125 mm x
0.125 mm
0.00492 in. x
0.00492 in.
0.125 mm x
0.125 mm
300 dpi 0.0033 in. x
0.0039 in.
0.084 mm x
0.099 mm
0.0033 in. x
0.0039 in.
0.084 mm x
0.099 mm
Maximum
print width
203 dpi 4.09 in. 104 mm
6.6 in. 168 mm
300 dpi 4.1 in. 106 mm
Minimum print length 1 dot row 1 dot row
Maximum
print length
203 dots/
inch
105 in. 2667 mm 65 in. 1651 mm
300 dots/
inch
45 in. 1143 mm 29 in. 737 mm
Bar code
modulus
(X) dimension
203 dots/
inch
5 mil to 50 mil 5 mil to 50 mil
300 dots/
inch
3.3 mil to 33 mil 3.3 mil to 33 mil
Programmable
constant print
speeds
203 dots/
inch
Per second:
7 in., 8 in., 9 in.,
10 in.
Per second:
178 mm,
203 mm,
229 mm,
254 mm
Per second:
7 in., 8 in.,
9 in., 10 in.
Per second:
178 mm,
203 mm,
229 mm,
254 mm
300 dots/
inch
Per second:
2 in., 3 in., 4 in.,
5 in., 6 in.
Per second:
51 mm,
76 mm,
102 mm,
127 mm,
152 mm
Per second:
2 in., 3 in.,
4 in., 5 in.,
6in.
Per second:
51 mm,
76 mm,
102 mm,
127 mm,
152 mm
Thin film printhead with energy control

Zebra Z4Mplus Specifications

General

Print Method	Thermal transfer or direct thermal
Resolution	203 dpi
Max Print Width	4.09 inches
Max Print Length	39 inches
Max Print Speed	10 inches per second
Memory	4 MB Flash, 8 MB DRAM
Interface	Parallel, Serial
Media Sensors	Reflective and transmissive
Media Width	0.79 inches to 4.5 inches
Media Length	0.38" (9.6 mm) to 39" (991 mm)
Ribbon Width	2 inches to 4.33 inches
Power Requirements	100-240 VAC, 50/60 Hz
Operating Temperature	40°F to 105°F
Storage Temperature	-40 to 140°F (-40 to 60°C)
Humidity	20 to 85% non-condensing
